    140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights

    Ask Lasest Price
    Brand Name : SUNLUXX
    Model Number : FAL-75W
    Certification : CE RoHs
    Price : US$113.84/PC , EXW price
    Payment Terms : T/T, Western Union
    Supply Ability : 6000 Pieces per Month
    Delivery Time : 3-5 work days
    • Product Details
    • Company Profile

    140LM/W 75W LED Sport Court Lighting Fixtures , IK10 IP66 LED Stadium Lights

    High Effeiciency IK10 75W LED Stadium Flood Light , IP66 , 5 Years Warranty


    Features

    1. 140lm/W high brightness , stable performance long longevity and low power consumption

    2. Stable current , by high efficient and wide voltage constant current driver

    3. Mounting bracket can be rotated 180 degrees to facilitate the installation

    4. It provides even, bright illumination across a wide area

    5. Waterproof design, ideal even for outdoor use

    6. IP66, IK10 protection, strong wind resistance, Ferrari Idea design make it higher performance.

    7. 5 years warranty.


    Technical Data


    Power75W
    Input Voltage90 - 305VAC
    Input Current0.68A@220VAC
    PF>0.9@220VAC
    DC Output Voltage48V
    DC Output Current2.9A
    Dimming (Optional)3 in one dimming(PMW, 1-10V,Resistor), DALI
    CCT4000k, 5000k, 5700K, 3000K and 2700K can be customized
    Ra>80,5000KTypical Flux19500lm±10%
    Efficiency130lm/W±10%
    Ra>70,5000KTypical Flux21000lm±10%
    Efficiency140lm/W±10%
    LED BrandNICHIA 3030
    Light TypeAsymmetric and symmetric polarized light
    Operation Temp.-40 to + 45 ℃
    Storage Temp.-40 ℃ to + 85 ℃
    Lifespan45℃ , 50,000 hours
    IP Class66
    IK Class10
    Lamp Body ColorGrey or as customized
    Product Size(mm)330*373*50
    Net Weight(kg)4.76
    Packing size(mm)540*460*190
    Gross Weight(kg)13.5
    Product Quantity Per Carton2pcs
    Installation MethodBracket Mount






    Beam Angle







    Accessories

    Light Distribusion Curve



    Installation Manual



    Applications

    Side Walk Lighting, Garden Lighting,Park Lighting,Billboard Lighting,Landscape Lighting,Building Lighting,Stadium Lighting.
