    0 - 10V Dimmable LED High Bay Warehouse Lighting Fixture , Hook Mount LED Lights

    Ask Lasest Price
    Brand Name : SUNLUXX
    Model Number : CHBL-120
    Certification : ETL, CE,SAA,ROHS,NSF
    Price : US$100.87/PCS unit for EXW item
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 5000 Pieces per Month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    0 - 10V Dimmable LED High Bay Warehouse Lighting Fixture , Hook Mount LED Lights

    Dimmable 0-10V 4000K 120W LED Food Processing Light Hook Mount For Meaty Shop Lighting


    LED Food Processing Light is waterproof, and have an IP67 rating.We can offer private custom:lampshade color choice:Red,Blue,Gray.

    We can also make it according to the color you like base on minimum order quantity 500PCS.


    Features of LED Food Processing Light


    1. These products have got NSF IP69K IK08 certification

    2. This product is mainly be used in clean food/ pharmaceutical and any other manufacture plant
    3. The product design with no screw on the front. So there is almost no dusty in smooth back, it is easy for clean and no
    screw or any other small part dropped when is cleaned by high-press water gun.

    4. The product surface coating get REACH/ROHS/HALOGEN test report by SGS

    5. The structure of lamp is made of aluminum alloy; the lens is made of optical grade material of Mitsubishi Corporation of Japan.

    The color of lamp is orange RAL2004

    6. The lens has been applied for patent and patent filings by Chinese custom,the record number is P2018-72651


    ItemCHBL-100CHBL-120CHBL-150
    Power100W120W150W
    Input Voltage90-305VAC90-305VAC90-305VAC
    Input Current0.47A@220VAC0.57A@220VAC0.68A@220VAC
    PF>0.90@220VAC>0.90@220VAC>0.90@220VAC

    Dimming Option

    MOSO

    2 in 1 dimming (PWM, 0-10V)2 in 1 dimming (PWM, 0-10V)2 in 1 dimming (PWM, 0-10V)

    Dimming Option

    Meanwell

    3 in 1 dimming (PWM, 0-10V, Resistor) / Dali3 in 1 dimming (PWM, 0-10V, Resistor) / Dali3 in 1 dimming (PWM, 0-10V, Resistor) / Dali

    Ra>80

    Luminous Flux

    14000Lm16800Lm21000Lm

    Ra>70

    Luminous Flux

    16000Lm19200Lm24000Lm
    LED BrandCree SMD 3030 / LUMILEDS 3030Cree SMD 3030 / LUMILEDS 3030Cree SMD 3030 / LUMILEDS 3030
    Beam Angle60°90°120°60°90°120°60°90°120°
    Operation Temp-40℃ ~ +45℃-40℃ ~ +45℃-40℃ ~ +45℃
    Storage Temp-40℃ ~ +85℃-40℃ ~ +85℃-40℃ ~ +85℃
    Lifespan25℃ 50000Hours25℃ 50000Hours25℃ 50000Hours
    IP ratingIP69KIP69KIP69K
    IK ratingIK10IK10IK10
    CertificatesETL, CE,SAA,ROHS,NSFETL, CE,SAA,ROHS,NSFETL,CE,SAA,ROHS,NSF
    Lamp Body ColorOrange( RAL2004)Orange( RAL2004)Orange( RAL2004)
    Product Size(mm)400*400*197400*400*197400*400*197
    Net Weight(kg)5.6kg5.6kg5.6kg
    Packing Size(mm)480*480*220480*480*220480*480*220
    Gross Weight(kg)6.8kg6.8kg6.8kg
    Installation WayHook Mount/Pendant MountHook Mount/Pendant MountHook Mount/Pendant Mount

    IP69K IP67 Water Testing



    FAQ for LED Food Processing Light


    Q1. How many kinds of LED products in your factory?

    A1: We have large range of LED products,Including LED High Bay Light (HBL,CHBL,BHB series),LED Flood Light (Slim FL3A series and FAL series),LED Canopy,LED Parking Lot,LED Post Top and LED Corn cob Lights.


    Q2. How about the lead time for this LED Food Processing Light?

    A2: Sample needs 3-6 days, mass production time needs 2-3 weeks based on the quantity


    Q3. How can i pay for my order?
    A3: We accept following payment: T/T (bank transfer),Western Union,Paypal transfer.Normally,For samples order below total amount US$1000.00,We advice customers using Paypal transfer.Above total amount US$1001.00,T/T (bank transfer) is much better for us.
    About the payment for bulk quantity order,Usually we ask for 30% deposit before the production and 70% balance paid before the shipping.


    Sunluxx Warranty


    1. Warranty time is 5 years and effected from the date of original purchase.
    2. Warranty is only available for customers who purchase directly from Sunluxx, during the warranty time:
    (1) New driver will be sent if driver failed.
    (2) New LED board will be sent if LED failed.
    (3) New Replacement will be sent depend on the level of damage or the specific causes of defectives.


    3. Warranty does not cover damages caused by abuse, misuse, improper environmental conditions, natural disaster,wrong installation,etc.

    We are so happy to serve you!


    Applications
